Leírás
| Operating type | L.V. |
| with SVC | No |
| Number of steps | 12 |
| Connection | 1 Phase, 1 Current |
| Current transformer ratio | Ok |
| Voltage transformer ratio | No |
| Voltage (phase-neutral) | 25-300V oc +-0.5% |
| Voltage( phase-phase) | No |
| Current | 50mA-6A +-0.5% |
| Cosφ & Pf | [+-0.000]-[+-1.000] |
| Active Power | +-1% |
| Reactive Power | +-2% |
| Apparent Power | No |
| Active Energy | No |
| Reactive Energy | No |
| THD V & THD I | No |
| Harmonic | No |
| Temperature Measurement | Ok |
| Fan and Alarm relay | Ok |
| Cosφ 2 for generator | No |
| Shunt reactor | No |
| Single phase capacitor | No |
| Three phase capacitor | Ok |
| Equal aging | No |
| Password protection | No |
| RS485 – MODBUS RTU | No |
| Step learning | Automatic |
| Supply voltage | 230V ac;50/60Hz; <10 VA |
| Display | LED Display |
| Over Voltage | Ok |
| Under Voltage | Ok |
| Over temperature | Ok |
| Over Harmonic | No |
| Step protection | Ok |
| Min response time | 1 sec |
| Ambient temperature | -5C….+50C |
| Storage temperature | -20C….+70C |
| Dimensions | 144x144x37mm |
| Quantity in 1 box | 5 |
