Leírás
Overall Size:23×23×29(mm)
Mounting Size: 22×22(mm)
Contact Arrangement Mode: SPST ( Single Pole Single Throw )
Tap Position: ON—OFF
Button Material: Plastic
Body Material: Plastic
Contact Material: Copper-Plating Silver
Terminal Type: Pin ( 2 terminals )
Button Colour:Red/Black/White
Body Colour:Black/White
Switch Rating: 6A 250VAC , 10A 125VAC
Contact Resistance: 35m? max
Insulation Resistance: 500VDC 100M? min
Dielectric Strength: 1500VAC, 1 Minute
Operating Temperature: ?25°c ~ +85°c
Electrical Life : ?10,000 Cycles
