Leírás
| Connection | 3P&4W,3P&3W,ARON |
| Voltage: V1, V2, V3 | 1-300 Vac;0,5 class |
| Voltage: V12, V23, V31 | 2-600 Vac; 0,5 class |
| Current:I1,I2,I3,I neutral | 2mA-6A;0,5 class |
| Active Power:P1,P2,P3 | No |
| Reactive Power:Q1,Q2,Q3 | No |
| PF1,PF2,PF3 | [+-0.000]-[+-1.000] |
| Demand ve Peak | Ok |
| Frequency | Ok |
| ALARMS | No |
| Relay output: max. 3A/240 Vac | No |
| RS485 – MODBUS RTU | No |
| Password protection | Ok |
| Ambient temperature | -5 C….+50 C |
| Storage temperature | -20 C….+70 C |
| Display | LED Display |
| Current Transformer | X/5A |
| Current transformer ratio | 1….5000 |
| Voltage transformer ratio | 1….4000 |
| Auxiliary supply voltage | 230 Vac <4VA |
| Dimensions | 96x96x56 mm |
| Quantity in 1 box | 12 |
